Seat Height 25.5''
|
|
Engine: Liquid cooled four-stroke single cylinder
|
|
Displacement: 244cc
|
|
Max Torque: 11.06 lbft @6500rpm
|
|
Max Power: 14 hp @7500rpm
|
|
Rated Power: 14 hp /7500r/min
|
|
Lubrication: Automatic
|
|
Spark Plug: NGK DPR7EAS
|
|
Starter System: Electric Start
|
|
Ignition System: CDI
|
|
Fuel System: Kehien carburetor
|
|
Transmission: Automatic CVT
|
|
Gasoline: 90 Octane
|
|
Engine Oil: SAE15W/40SF
|
|
Overall Width: 29.3 in
|
|
Overall Height: 53.3 in (with tall windshield)
|
|
Wheel base: 64 in
|
|
Overall Length: 89.2 in
|
|
Dry Weight: 372 lbs
|
|
Ground Clearance: 5.7 in
|
|
Front Suspension: Hydraulic Telescopic Fork
|
|
Rear Suspension: Dual Shock
|
|
Front Brake: Hydraulic Disk, Hand Control
|
|
Rear Brake: Cable Drum, Foot Control
|
|
Front Tire: 110/90-12
|
|
Rear Tire: 120/90-10
|
|
Top Speed: 105 KM/h (65 mph)
|
|
Battery: Lead Acid 12V 9AH
|
|
Max Load: 330 lbs
|
|
Carton Size: 84" x 30" x 45"
|
|
Carton Weight: 487 lbs
|
|
